S image of P30B06010DXV20

P30B06010DXV20

by Sanyo Denki
$566.64 - $566.64
$566.64
$566.64 - $566.64
$566.64

In Stock, Ships Fast

The Sanyo Denki P30B06010DXV20 from the P3 Super BL Servo Motors series is a compact yet powerful industrial automation component, delivering a 100 W rated output through its 60 mm flange size for streamlined installation. It operates at a rated speed of 3000 min? and reaches a maximum speed of 4500 min?, providing 0.32 Nxm rated torque and a 0.316 Nxm/Arms torque constant. With a continuous stall torque of 0.34 Nxm and an instantaneous maximum stall torque of 0.98 Nxm, it withstands short overloads reliably. Electrical characteristics include a rated armature current of 1.1 Arms, phase armature resistance of 1.5 ?, and an electric time constant of 3.8 ms, ensuring fast response and efficient power usage in space-constrained applications.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Continuous Stall Armature Current

1.2 Arms (approx.)

Continuous Stall Torque

0.34 Nxm (approx.)

Electric Time Constant

3.8 ms

Flange Size

60 mm

Induced Voltage Constant

11.0 ~ 10% mV/(min?)

Instantaneous Maximum Stall Armature Current

4.3 Arms (approx.)

Instantaneous Maximum Stall Torque

0.98 Nxm (approx.)

Maximum Rotating Speed

4500 min?

Mechanical Time Constant

0.63 ms

Phase Armature Resistance

1.5 ?

Rated Armature Current

1.1 Arms (approx.)

Rated Output

100 W (estimated based on similar model scaling)

Rated Rotating Speed

3000 min?

Rated Torque

0.32 Nxm (approx.)

Torque Constant

0.316 Nxm/Arms (approx.)
