S image of P30B06020DXS50

P30B06020DXS50

by Sanyo Denki
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message

The Sanyo Denki P30B06020DXS50 servo motor from the P3 Super BL Servo Motors series delivers precise motion control for industrial automation. This 60 mm square flange unit features an ABS-R II sensor for absolute position detection, a torque of 0.637 Nm and a maximum speed of 3000 min⁻¹. Powered by 200 V AC and rated at 200 W output with a 2.2 A current draw, it offers efficient performance. An armature winding inductance of 6.00 mH and resistance of 1.43 ohm enhance electrical responsiveness. The sealed connector with oil seal protects against dust and moisture, while its compact housing and 2.3 kg weight simplify integration without a brake option for reduced maintenance.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Armature Winding Inductance

6.00 mH

Armature Winding Resistance

1.43 ohm

Brake Option

No brake installed

Connector Type

With oil seal and connector

Housing Dimensions

60 mm square flange

Interfaces

3 USB Ports

Maximum Rotational Speed

3000 min⁻¹

Mounting Type

DIN Rail

Power Supply

100-240 VAC

Rated Current

2.2 A

Rated Output Power

200 W

Rotor Moment of Inertia

0.244 × 10⁻⁴ kg·m²

Torque

0.637 Nm

Voltage Type

200V AC

Weight

2.3 kg
