P30B06040DXS22E
by Sanyo Denki
The P30B06040DXS22E servo motor from Sanyo Denki in the P3 Super BL Servo Motors series delivers robust performance for demanding industrial applications. This model provides a rated output of 400 W and a rated torque of 1.274 Nm at a rated rotating speed of 3000 min⁻¹ with a maximum rotating speed of 4500 min⁻¹. It features an instantaneous maximum stall torque of 3.82 Nm and a torque constant of 0.533 Nm/Arms for precise dynamic response. The motor’s phase armature resistance of 1.4 Ω is optimized for efficient current flow, while the rated armature current of 2.7 Arms ensures reliable continuous operation. These primary specifications establish the P30B06040DXS22E as a high-performance solution for precise motion control.
Performance characteristics of the P30B06040DXS22E are engineered for rapid response and stability under load. The low rotor inertia (inc) of 0.255 × 10⁻⁴ kg·m² minimizes lag in acceleration, and the induced voltage constant of 18.6 ±10% mV/min⁻¹ supports smooth speed control. When paired with the Applicable Amplifier Model PU0A030/PZ0A030, the motor achieves optimal drive performance. Integrated brake options include a brake holding torque of 1.274 Nm with brake inertia of 0.06 × 10⁻⁴ kg·m² and a brake mass of 0.44 kg, enabling secure stops in safety-critical processes. The instantaneous high-value stationary rotor torque of 3.82 Nm under stall conditions ensures the motor can withstand abrupt load changes without losing position.
The P30B06040DXS22E is built for reliability and seamless integration into automated systems. Its insulation is rated class F with 1500 VAC dielectric strength for 60 seconds and a resistance test of 10 × 10⁶ Ω at 500 V DC, ensuring electrical longevity. The motor operates in temperatures from 0 to 40°C at up to 90% RH (non-condensing), supporting a wide range of factory environments. Compact and lightweight at 1.7 kg including encoder, it simplifies mounting and minimizes inertial impact on mechanical systems. Ideal for pick-and-place units, conveyor controls, and general industrial automation, the P30B06040DXS22E provides dependable motion control where precision and uptime are critical.
