P50B05005DXS50

The P50B05005DXS50 AC servo motor from Sanyo Denki is a precision drive solution within the renowned P5 Super BL Servo Motors series. This compact unit delivers a Rated Power: 0.5 kW output while operating at a Rated Voltage: 200 V AC and drawing Rated Current: Approximately 6.5 A. Featuring a Frame Size: Standard frame (approx. 50 mm class) and a robust Motor Type: AC Servo Motor configuration, it is optimized for demanding industrial automation environments. Designed for Duty Cycle: Continuous operation, this motor maintains consistent performance under extended runtime. The device supports a Control Mode: Digital Position Control interface, ensuring precise motion profiles and seamless integration with modern CNC and robotic controllers. Its Protective system: Totally enclosed housing and Vibration class: V15 compliance guarantee stable operation in harsh factory settings.

Performance is enhanced by an advanced Excitation system: Permanent magnet type, which yields high torque density and efficient energy conversion. Integrated Feedback Device: Integrated Resolver/Encoder provides reliable position feedback, including incremental encoder functionality, for rapid response and sub-micron accuracy. Thermal management relies on a Cooling Method: Forced air cooling system that keeps the motor within safe thermal limits. Mechanical robustness is demonstrated by flange-mounted installation, supporting up to 15 kg of radial load and 8 kg of thrust load during active operation (20 kg during assembly). The Mounting Type: Flange mounting and Installation Method: Flange type interface simplifies installation, while the absence of a holding brake reduces inertia and mechanical complexity.

Reliability is assured by an IP Protection Class: 55 rating that shields internal components from dust ingress. Continuous operation at ambient temperatures up to 45 °C is feasible without performance degradation. The motor’s flange design and standard frame dimensions facilitate straightforward integration into existing drive systems, with compatibility across a wide range of Typical Applications: Industrial CNC machinery, robotics, and automation. With its balanced combination of torque, speed, and precision, the P50B05005DXS50 is well suited for high-accuracy indexing, pick-and-place, and closed-loop positioning tasks in advanced manufacturing environments.
