P50B08075HBVT3E

The Sanyo Denki P50B08075HBVT3E is a high-performance AC servo motor from the renowned P5 Super BL Servo Motors series by Sanyo Denki. This compact unit delivers a Rated Output of 750 W and a Rated Rotating Speed of 3,000 min⁻¹, supported by a Torque Constant of 0.689 Nm/Arms for precise torque generation. The motor provides a Rated Torque of 2.381 Nm and a Continuous Stall Torque of 294 Nm, ensuring sustained performance under varying load conditions. Featuring a Flange Size of approximately 86 mm, the motor adopts a Flange mounting installation method for straightforward integration. Weighing 3.9 kg (excluding wiring), it offers an optimal power-to-weight ratio suited to industrial automation systems.

Performance is further enhanced through tightly controlled electrical characteristics. The servo’s Phase Armature Resistance is 1.07 Ω, with an Electrical Time Constant of 5.3 ms to facilitate rapid current response. It supports an Instantaneous Maximum Stall Armature Current of 15.3 Arms, enabling high peak torque during acceleration and deceleration phases. The Applicable Load Inertia rating of 19.26×10⁻⁴ kg·m² aligns with mid-load industrial applications, while the Excitation System based on a permanent magnet ensures efficient energy conversion. The motor’s Maximum Rotating Speed reaches approximately 4,500 min⁻¹, allowing dynamic operation in high-speed positioning tasks. A robust Dielectric Strength rated at 1,500 VAC for 1 minute and Insulation Rating of F type (500 VDC, 10 MΩ) contribute to electrical safety and long-term stability.

The P50B08075HBVT3E is built for reliable operation in harsh environments, featuring an IP55 Protection Rating and Ambient Humidity tolerance from 20 to 90% (non-condensing). Its Fully closed, self-cooling design ensures consistent thermal management, while the integrated Seal Presence guards against particulate ingress. The motor’s Holding Brake delivers a Holding Torque of 2.94 Nm, operates on 24 V or 90 V ±10% DC with excitation currents of 0.33 A or 0.08 A, and features a brake inertia of 0.343×10⁻⁴ kg·m² in a compact 0.8 kg housing. Storage conditions from –20 to 65°C and compliance with industrial vibration standards ensure seamless integration into conveyor systems, robotics, packaging machinery, and other automation platforms.
