S image of P50B08100VCXS9

P50B08100VCXS9

by Sanyo Denki
$1,361.25 - $4,500.00
$1,361.25
$1,361.25 - $4,500.00
$1,361.25

In Stock, Ships 1 - 3 Days

The P50B08100VCXS9 from Sanyo Denki delivers a torque of 3.18 N·m and 1000 W power. Part of the P5 Super BL Servo Motors, it has IP55 protection and runs on 200 V AC. The motor reaches 4500 RPM with natural convection cooling and a 16 mm keyed splined shaft.

It features a 24 V DC holding brake with 2.94 N·m static torque and 8.1 Arms current. The insulation class is F and dielectric strength is 1500 VAC for one minute. It operates from 0 °C to 40 °C and stores from -20 °C to 65 °C.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Controller Type

Digital

Flange Size

80 mm

Frequency

50 Hz

Holding Brake Voltage

24 V DC

Insulation Class

F (WDG F)

Insulation Resistance

≥10 MΩ at 500 VDC

Maximum Speed

4500 min⁻¹ (RPM)

Mounting Type

Wall-mountable

Phase

3-phase

Power Connector

1x Black rectangular

Power Rating

5 kW

Protection Rating

IP55 (Dust Protected & Water Jet Resistant)

Rated Power

1000 W (1 kW)

Torque Constant (KT)

0.393 N·m/Arms

Voltage

220 V
