P50C07040HXS23

The Sanyo Denki P50C07040HXS23 servo motor from the P5 Super BL Servo Motors series is engineered for demanding industrial automation applications, delivering 400W of rated output power and a rated rotating speed of 4,500 min⁻¹. Its robust design features a sealed enclosure rated IP67 to withstand dust ingress and water immersion, ensuring reliable operation in harsh environments. The motor achieves a maximum torque of 14.8 N·m while offering a rated torque of 8.5 N·m and maintains smooth performance across the full speed range. Operating from an electrical input voltage range of 200-230VAC, it balances high output with efficient energy use. Fabricated on a 76 mm square flange with a straight shaft and keyway, this unit simplifies mounting and torque transmission.

The P50C07040HXS23 hosts a comprehensive array of critical specifications for precision control. It supports an ambient operating temperature of 0 to +40°C and a storage temperature range of -20 to +65°C to withstand installation and maintenance phases. With a mass of 7.4 kg and flange dimensions of 70 × 70 mm, it offers a compact footprint for tight machine layouts. The motor’s insulation grade is rated F Type and its protection system meets IP67 standards. Electrical characteristics include a phase resistance of 1.15 Ohms, a continuous stall torque of 7.4 N·m, and a torque constant of 0.7 N·m/Arms. Brake excitation is provided at 90V, ensuring controlled deceleration in safety-critical scenarios.

Operational performance is further enhanced by its high-resolution feedback and robust winding design. The integrated incremental encoder provides a resolution of 2000 P/R to deliver precise position tracking and simplify cable routing. At full load, the motor draws approximately 2.1 A and maintains stable operation in relative humidity from 20% to 90% (non-condensing). Vibration resistance up to industrial servicing level V10 and reliable function at altitudes below 1000 m expand its suitability across diverse manufacturing sites. Self-cooling features within the sealed housing regulate internal temperatures, eliminating the need for external cooling accessories.

System integrators benefit from straightforward compatibility with standard servo drives and motion controllers, leveraging the P50C07040HXS23’s flange-mounted form factor and keyway shaft for direct coupling. Its IP67-rated enclosure and F-class insulation ensure long-term durability in conveyor systems, robotic arms, packaging lines, and CNC machinery. The combination of high torque density, compact size, and comprehensive feedback capabilities makes this servo motor an ideal choice for precision positioning, high-speed indexing, and continuous dynamic motion applications in industrial automation.
