The PBM423DXA20 is a 42 mm sq servo motor by Sanyo Denki in the PB SANMOTION Servo Motors series. It offers a max stall torque of 0.35 N·m and rated speed of 0 to 4500 min-1. An optical incremental encoder with 2000 Pulse/Rev ensures precise feedback. Weighing 0.5 kg, it runs on 24 VDC ±5%, withstands 47 N radial and 9.8 N thrust loads, and operates between 0 to +55°C.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Allowable Radial Load
47 N
Allowable Thrust Load
9.8 N
Encoder Resolution
2000 Pulse/Rev
Encoder Type
Optical incremental
Max Input Current (excitation Current)
0.1 A
Max Stall Torque
0.35 N·m
Motor Length
88.3 mm
Motor Mass
0.5 kg
Motor Size
42 mm sq.
Operating Temperature
0 to +55°C
Power Supply Voltage
24 VDC ±5%
Protection Class
Class I
Rated Speed
0 to 4500 min-1
Storage Temperature
-20 to +65°C
Vibration Resistance
5 m/s2 (10 to 55 Hz)
