PPC-P11.1N-N-Q1-NN-NN-FW

Request a quote
The PPC-P11.1N-N-Q1-NN-NN-FW is a digitally-enhanced, stand-alone multi-axis controller created by Bosch Rexroth Indramat. This system, driven by VisualMotion GMP10 firmware, is designed to directly connect into a PC's PCI slot, offering plug and play capabilities with dynamic PC memory management. The optional interface card includes digital inputs and outputs for superior communication capabilities. The device boasts a 32 bit, 33 MHz PC bus connection, and optional components such as a front faceplate, a programmable limit switch card, and a DAQ03 link ring. It also features a 1-digital 7-segment display, drive-based I/O support, a compact flash memory card (supporting up to 32MB), and a Sercos interface that can manage up to 40 drives. Additional features include two serial interface ports with adjustable baud rates, and operating system compatibility with Windows NT4.0; SP6 with VisualMotion 09vRS, and the VentureCom RTX 4.3.2 runtime environment. The controller unit requires a 3.3V to 12V power supply and operates most efficiently at temperatures from 0 to 45°C (32 to 113°F) at atmospheric pressures between 860hPa to 1080hPa.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Model: PPC-P11.1N-N-Q1-NN-NN-FW
  • System Type: Multi-axis stand-alone digitalized logic and motion control
  • Firmware: GMP10 VisualMotion
  • Interface: PC PCI slot compatible
  • PC Bus Connection: 32 bits
  • Frequency: 33 MHz
  • Additional Features: Optional front faceplate, programmable limit switch card (NSW01), DAQ03 link ring
  • Logical Control Hardware: 1-digital 7 segment display, I/O support drive-based, compact flash memory card (32Mbs), Sercos interface (Managing up to 40 drives)
  • Serial Interface Ports: 2
  • Baud Rate: Software-selectable (9600-115200)
  • Default Bauds: 9600
  • Additional Interface: Option card switch, link ring, Encoder interface card
  • Operating System Requirement: Windows NT4.0; SP6 with VisualMotion 09vRS and VentureCom RTX 4.3.2 RUN-Time environment
  • Mounting: Standard PC PCI bus
  • Power Supply Voltage: 3.3V-+12V
  • Operating Temperature: 0°C to 45°C (32°F to 113°F)
  • Ambient Atmosphere Pressure: 860hPa to 1080hPa
  • Operating Elevation: Up to 1500 meters.
