product Main (Front Left) image of PPC-R22.1N-N-N1-N2-P2-FW

PPC-R22.1N-N-N1-N2-P2-FW

by Bosch Rexroth Indramat
Request a quote
The PPC-R22.1N-N-N1-N2-P2-FW is a motion and logic control model crafted by reputable manufacturers Bosch Rexroth Indramat. Suitable for IndraDrive, EcoDrive digital servo drives, and DIAX 04, this model uses the SERCOS interface for real-time control-servo drive communication and comes with 3 expansion slots. Powered by a 24 VDC dc-link voltage supply, it comprises a PLS module and the capacity for two optional PLSs with a current draw of 250 mA each. Also featured is a PROFIBUS-DP slave interface with diagnostic LEDs, controlled using the GPP 10 firmware and VisualMotion Toolkit software. This model includes a 4-digit H1 status display and an S2 reset button. It has a maximum current consumption of 1.2 A, an operating temperature range of 0 to +45 degrees Celsius, and IP20 protection class.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product: PPC-R22.1N-N-N1-N2-P2-FW
  • Type: Motion/Logic Control
  • Compatible Drives: IndraDrive, EcoDrive digital servo drives, and DIAX 04
  • Designed For: Control of up to 40 intelligent drives
  • Mounting: Directly into Reco 02 rack on TS 35×27×15 DIN rails
  • Interface: SERCOS interface
  • Expansion Slots: 3
  • Power Supply: 24 VDC dc-link voltage
  • Additional Module: PLS master and slave module
  • PLS Outputs: 16 outputs per card (up to 2 cards)
  • Current Draw Per Output: 250 mA
  • PLS Outputs Update: Every 250 microseconds
  • Communication Interface: PROFIBUS-DP slave interface
  • Diagnostic LEDs: 4 on front panel
  • Programming Software: VisualMotion Toolkit
  • Firmware Module: GPP 10
  • Display: H1 4-digit status display
  • Reset Button: S2
  • Max Current Consumption: 1.2 A
  • Temperature Range: 0 to +45 degree Celsius
  • Protection Class: IP20
