PPC-R22.1N-T-Q1-P2-NN-FW

by Bosch Rexroth Indramat
Request a quote
The PPC-R22.1N-T-Q1-P2-NN-FW, manufactured by Bosch Rexroth Indramat, is a programmable control system integral to managing up to 40 Bosch digital drives. This multi-axis motion/logic control system elegantly embraces the Bosch Rexroth VisualMotion 10 product line. Ensuring seamless operability, the main features include a display toggle button, transmit and receive interfaces for a fiber optic-based SERCOS interface, and three optional expansion slots, among others. It also houses a pre-installed PROFIBUS-DP slave module while the firmware must be ordered separately. The module fits into a Bosch Rexroth Reco 02 rack, requiring 24 volts DC input and drawing a maximum of 1.2 Amps from the power supply. With dimensions of 184x82x165mm and weighing 1.3kg, the system should be kept within an operating temperature range of 0 - 45 degrees Celsius to maintain optimal performance.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Model: PPC-R22.1N-T-Q1-P2-NN-FW
  • Product Type: Programmable Control System
  • Design: Control of maximum 40 digital drives
  • Control System: Multi-axis motion / logic control
  • Product Line: Rexroth VisualMotion 10
  • Interface: Transmit and receive interfaces for fiber optic based SERCOS interface
  • Additional Ports: Serial port for programming, serial port for communication, and Ethernet status LED
  • Network Port: Ethernet
  • Module: Does not include a memory expansion module
  • Rack Compatibility: Bosch Rexroth Reco 02 rack
  • Mechanical Dimensions: 184 x 82 x 165 millimeters
  • Weight: 1.3 kilograms
  • Installation: Slot 00 of the rack
  • Module Expansion: Slots for I/O modules
  • Installation Direction: Vertical
  • Operating Temperature: 0 to 45 degrees Celsius
  • Non-Operating Temperature: -25 to 70 degrees Celsius
  • Special Module: PROFIBUS-DP slave module
  • Firmware: Not included, needs to be ordered separately
  • Input Requirement: 24 Volts DC
  • Maximum Current: 1.2 Amps
  • Voltage Drop Off: Below 20 Volts DC
  • Power-Fail Signal: Activated when voltage drops off below 20 Volts DC.
