PPC-R22.1N-T-Q2-G2-NN-FW
The Bosch Rexroth Indramat PPC-R22.1N-T-Q2-G2-NN-FW is a versatile logic and motion control unit from the distinguished PPC Controllers series. Designed for commercial machinery applications, this unit leverages a 24 VDC power supply as its rated value and adheres to a tolerance of -15% / +20% (according to EN61131-2 1994). Its design integrates key functionalities that ensure proper management of high discharge current and elevated voltage levels during operation, thus facilitating reliable performance in industrial settings.
Engineered with precision, the PPC-R22.1N-T-Q2-G2-NN-FW presents a well-defined permissible operating range of 19.2 ... 30 VDC (ripple factor included), ensuring that even with inherent voltage variations, the unit functions optimally. Attention to technical detail is evident as the system is designed to accommodate power fluctuations and meet strict EN standards. The integration of a ready-for-operation relay, with a proven switch cycle longevity of at least 500,000 cycles when adequately protected, further distinguishes this module for demanding industrial applications.
The control unit is mounted using RMB02.2 racks on a TS 35x27x15 DIN rail, guaranteeing stability even under rigorous conditions. Additional features include the incorporation of an H1 LED display on top for effective status monitoring and the assurance that the housing operates safely when used as directed. Installation guidelines specify a vertical upright positioning, and the system is equipped with inherent safety measures such as a mandatory safety conductor connection, emergency stop accessibility, and adherence to national safety regulations. The PPC-R22.1N-T-Q2-G2-NN-FW thus offers reliability, efficiency, and robust performance for modern industrial automation needs.
