PS-DA0408-011

Original price $0.00 - Original price $0.00
Original price
Request a Quote
$0.00 - $0.00
Current price Request a Quote

Request a quote

Add a Message

The PS-DA0408-011 from Beckhoff operates at 50 kHz frequency and supports a lamp start-up voltage of 1,700 Vrms. Part of the PS Power Supplies series, it delivers 615 Vrms output voltage per lamp and draws approximately 1.61 A at 12 VDC input. It features a remote ON/OFF switch, a current balance circuit, and provides independent open lamp detection for enhanced safety.

The inverter accepts 10.8 to 13.2 VDC input and weighs approximately 40 grams with compact dimensions of 160 mm x 26 mm x 12 mm. It includes a 12-pin CN1 input connector and four 2-pin CN2 to CN5 output connectors for lamp power distribution. RoHS compliant, it operates reliably from -10°C to +60°C ambient temperatures.

Contact Us

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Dimensions (L x W x H)


160 mm x 26 mm x 12 mm

Input Connector (CN1)


12-pin connector for power and signals

Input Current (Iin)


Approximately 1.61 A at 12 VDC

Input Voltage (Vin)


10.8 to 13.2 VDC

Lamp Start-Up Voltage


1,700 Vrms at 12 VDC input

Operating Frequency (F)


50 kHz

Operating Temperature Range


-10°C to +60°C

Output Connectors (CN2 to CN5)


2-pin connectors for each lamp

Output Current (Iout)


6.5 mArms per lamp

Output Voltage (Vhigh)


615 Vrms per lamp

Remote ON/OFF Control


Supported

RoHS Compliance


Yes

Weight


Approximately 40 grams
