manufacturer image of PST625E.133-W

PST625E.133-W

by Bosch Rexroth Indramat
$9,893.07 - $9,893.07
$9,893.07
$9,893.07 - $9,893.07
$9,893.07
Available, Shipping Varies
The Bosch Rexroth Indramat PST625E.133-W is an advanced weld controller designed for resistance welding, with a power reach of up to 155 kVA. Weighing 8kg, this device houses a state-of-the-art temperature monitoring unit and a thyristor power unit for heat generation. Distinguished by a 230 Amp rated current and a duty cycle rating of 50%, it offers an optional programming interface and is equipped with a voltage-dependent resistor (MOV) for overvoltage protection. This controller, which can be fitted into an enclosure or switchgear cabinet, utilizes water cooling with a 4L/min min flow rate and a 0.2 max bar pressure drop. The PST625E.133-W can be mounted vertically or on its rear and complies with IP 20 regulations for material protection. The device operates within a 0-2000 meters altitude range at an air temperature not exceeding 55 degrees Celsius, with a storage transport temperature of -25 to 70 oC. The box terminal electrical connection accommodates a max area of 95 mm2, and the max output of the primary current is 400 Amps at a 30% duty cycle.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Name: PST625E.133-W Weld Controller
  • Weight: 8 kg
  • Application: Resistance welding
  • Power Rating: Up to 155 kVA
  • Protection Feature: Voltage-dependent resistor (MOV: metal-oxide varistors)
  • Thyristor Power Unit: Yes, integrated for heat generation
  • Weld Timer: Yes, built-in for process monitoring
  • Nominal Rated Current: 230 Amps
  • Maximum Duty Cycle: 50%
  • Cooling Method: Water-cooling with 4L/min flowrate and 0.2 bar maximum pressure drop
  • Mounting: Optional, Enclosure, Switchgear cabinet, Vertical or Rear mount
  • Material Protection Category: IP 20
  • Electrical Connections: Box terminal with max. 95mm2 core area
  • Installation Altitude: 0 - 2000 meters a.s.l
  • Maximum Operational Temperature: 55 degrees C
  • Storage/Transport Temperature Range: -25 to 70 degrees C
  • Primary Output Current: Max 400 Amps at 30% duty cycle.
