S image of QH1L034B-01

QH1L034B-01

by Sanyo Denki
$2,925.00 - $2,925.00
$2,925.00
$2,925.00 - $2,925.00
$2,925.00

In Stock, Ships 1 - 3 Days

The Sanyo Denki QH1L034B-01 appliance from the Q SANMOTION Servo Amplifiers series is a high-precision industrial servo amplifier designed to control three-phase AC servo motors with ease. Featuring an Input Voltage: AC 200V requirement and a Rated Output: 500 to 1500 W, it supports both torque and speed control via analog commands (DC 0–2.0 V). With a Calorific Value: 11 to 169 W range, the QH1L034B-01 provides sufficient thermal headroom to maintain stable operation under varying loads and ambient conditions, making it ideal for industrial automation applications.

Internally, the amplifier accepts both analog command inputs and digital pulse signals for maximum versatility. It offers a dual-mode command interface: Analog Command Input: DC 0–2.0 V (torque/speed) and Pulse Command Input: digital pulse signals. The unit’s control circuitry draws Control Power: 30 VA and incorporates an NF30-shaped circuit breaker rated 10 A or 15 A for protection. Communication is handled by a serial interface supporting both async/ASCII and sync (Manchester) protocols, while firmware updates and parameter adjustments are easily performed via Q-SETUP software (trace & JOG). The amplifier is equipped with a Sumitomo 10250-52A2JL connector (CN1) and noise suppression filters (RF3010-DLC and RF3030-DLC for high models) to ensure electromagnetic compliance.

Built to withstand harsh industrial environments, the QH1L034B-01 operates reliably from 0 to 55 °C and up to 90% RH, with storage capability from -20 to +65 °C. It offers comprehensive protection against overcurrent, overload, regeneration faults, and overheating. Main wiring supports AWG16/14 (1.25/2.0 mm²) and AWG12 (3.5 mm²) conductors and a power supply range of 0.8 to >3 kVA. The amplifier is UL-listed and CE-marked, ensuring global safety and compliance standards. It is compatible with Q1AA06040D and Q1AA07075D servo motors and delivers efficient, precise motor control—making it a robust solution for modern industrial automation and motion control installations.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Amplifier Models

QS1A01, QS1A03, QS1A05

Analog Command Input

DC 0–2.0V (torque/speed)

Calorific Value

11 to 169 W

Circuit Breaker

NF30 shape, rated 10A or 15A

Connector CN1

Sumitomo 10250-52A2JL

Control Power

30 VA

Input Voltage

AC 200V

Main Wire Diameters

AWG16/14: 1.25/2.0mm²; AWG12: 3.5mm²

Motor Compatibility

Q1AA06040D, Q1AA07075D

Noise Filter EMC

RF3010-DLC; RF3030-DLC for high models

Operating Humidity

<90% RH

Operating Temp

0 to 55°C

Power Supply

0.8 to >3 kVA

Protection

overcurrent, overload, regen, overheat

Pulse Command Input

digital pulse signals

Rated Output

500 to 1500 W

Serial Output Interface

async/ASCII or sync (Manchester)

Software Upgrades

via Q‑SETUP (trace & JOG)

Storage Temp

-20 to +65°C
