R-IB IL 24 DO 2-2A-PAC

Name: R-IB IL 24 DO 2-2A-PAC
Brand: Bosch Rexroth Indramat
Price: 1106.46 USD
Availability: InStock

by Bosch Rexroth Indramat

$556.71 - $1,106.46

$556.71

$556.71 - $1,106.46

$556.71

The R-IB IL 24 DO 2-2A-PAC from Bosch Rexroth Indramat features two digital outputs and a 24 V DC nominal voltage. Part of the R-IB Interface Modules series, it offers short-circuit and overload protection and runs at 500 kbaud. This module measures 12.2 x 120 x 71.5 mm, weighs 61 g and features IP20 protection.

It operates from -25°C to +55°C and tolerates 10% to 95% humidity. Powered by a 24 V DC segment supply, it draws up to 4 A. Error messages signal short-circuit or overload faults.

Contact Us

Email: sales@servosupplier.com

Phone Number: 1-888-551-3082

International: 1-919-443-0207

Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Actuator Connection Type

2, 3, and 4-wire connection

Differential Voltage At Inom

≤ 1 V

Digital Outputs

Error Message To The Higher-level Control System

Short-circuit/overload of an output

Logic Voltage

7.5 V

Nominal Current Consumption From Us

Max. 4 A (2 x 2 A)

Nominal Current Inom Per Channel

2 A

Nominal Output Voltage Uout

24 V DC

Power Consumption From Local Bus Ul

Max. 35 mA

Protection

Short-circuit/overload

Segment Supply Voltage Us

24 V DC (nominal)

Signal Delay Upon Power Down (nom. Resistive Load)

Typ. 200 µs

Signal Delay Upon Power Up (nom. Resistive Load)

Typ. 200 µs

Total Current

4 A

Transmission Speed

500 kbaud
