S image of R-IB IL 24 DO 32/HD

R-IB IL 24 DO 32/HD

by Bosch Rexroth Indramat
$1,261.98 - $1,261.98
$1,261.98
$1,261.98 - $1,261.98
$1,261.98

Available, Shipping Varies

The R-IB IL 24 DO 32/HD by Bosch Rexroth Indramat is an interface module in the R-IB Interface Modules series providing 32 digital outputs at 24 V DC with 0.5 A nominal channel current. It features short-circuit/overload protection, a 1-wire actuator connection, 7.5 V logic voltage, and draws 140 mA from Ul and up to 8 A from Us. Operating in process data mode with signal delays of 500 µs on power-up and 1 ms on power-down, it ensures reliable industrial automation performance.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Actuator connection type

1‑wire

Current tolerance

±10 %

Differential voltage at Iₙₒₘ

≤1 V

Logic voltage (Vₗₒgᶜ)

7.5 V

Max. current consumption from Us

8 A (16×0.5 A)

Max. power consumption from Ul

140 mA

Nominal channel current Iₙₒₘ

0.5 A

Number of digital outputs

32

Operating mode

Process data, 32‑bit

Output voltage Uₒᵤₜ

24 V DC

Protection

Short‑circuit/overload

Segment supply voltage Us

24 V DC (nominal)

Signal delay on power down

1 ms (12 Ω/48 W, typ.)

Signal delay on power up

500 µs (12 Ω/48 W, typ.)
