R-IB IL AO 1/SF-PAC

Name: R-IB IL AO 1/SF-PAC
Brand: Bosch Rexroth Indramat
Price: 582.45 USD
Availability: InStock

by Bosch Rexroth Indramat

$468.36 - $582.45

$468.36

$468.36 - $582.45

$468.36

The R-IB IL AO 1/SF-PAC is an input module from Bosch Rexroth Indramat’s R-IB Interface Modules series, offering a basic error limit of ±0.003% and 16-bit resolution across voltage ranges of 0 to 10 V and current outputs of 0–20 mA/4–20 mA via a 2-wire connection. Operating between -25 and +55°C and transmitting data at 500 kbaud with process data update times under 1 ms, it features typical power consumption of 36 mA from the local bus and 75 mA from UANA at 24 V DC with a 7.5 V logic voltage. Rated IP20 and designed for DIN rail mounting within a 24.4 mm-wide housing, this module ensures reliable analog signal control for industrial applications.

Contact Us

Email: sales@servosupplier.com

Phone Number: 1-888-551-3082

International: 1-919-443-0207

Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Actuator Connection Type

2-wire connection

Ambient Temperature (operation)

-25 to +55°C

Basic Error Limit

±0.003%

Error Message To Higher-level Control System

Failure of supply voltage UANA

Logic Voltage Ul

7.5 V

Operating Mode

Process data mode 32 bits

Output Load (current Output)

0 to 500 Ω

Output Load (voltage Output)

Min. 2 kΩ

Peripheral Supply Voltage Uana

24 V DC

Power Consumption From Local Bus Ul

Typical 36 mA, Max. 45 mA

Power Consumption From Uana

Typical 75 mA, Max. 95 mA

Process Data Update

< 1 ms including conversion time of D/A converter

Resolution

16 bits

Transmission Speed

500 kbaud

Voltage Ranges

0 to 10 V
