R11F432565

The Sanyo Denki R11F432565 servo motor from the ABS Super Servo Motors series represents a high-performance solution for industrial automation, combining a compact form factor with robust control capabilities. Manufactured by Sanyo Denki, this AC servo motor delivers rated power of 1.0 kW at 200V AC and employs advanced AC vector control to achieve precise motion profiles. With a 150% overload capacity, it handles rapid acceleration and deceleration cycles without compromising reliability. The motor’s natural cooling design eliminates the need for external fans, reducing noise and maintenance requirements. Its IP54 rating ensures protection against dust ingress and splash water, making it suitable for diverse production environments.

The R11F432565 integrates a comprehensive set of technical specifications to support demanding applications. It features a Terminal Block connection type for secure electrical interfacing and a Foot-Mounted mounting style compatible with standard industrial frames. Feedback is provided by an Encoder system that continuously monitors shaft position and speed. The motor operates at 50/60 Hz line frequency, drawing a rated current of 4 A under nominal load. It supports environments with up to 90% humidity and weighs just 0.5 kg, facilitating installation in space-constrained assemblies. The compact 40 mm flange size ensures mechanical compatibility with belt drives, gearboxes, and robotic end effectors. Its insulation system is designed to withstand thermal and dielectric stresses, enhancing long-term durability.

Operationally, the R11F432565 delivers responsive torque control through its AC vector control loop, maintaining speed stability even under fluctuating loads. The 150% rated current overload capability allows short bursts of high torque output, making it ideal for indexing and pick-and-place tasks. Natural cooling relies on a black-coated housing that dissipates heat efficiently, preserving performance without additional Ventilation. The integrated encoder feedback enables real-time adjustments in position and velocity, ensuring repeatable motion accuracy. Its foot-mounted design provides rigid support, while the terminal block connections simplify wiring during field maintenance.

This servo motor is designed for seamless integration with standard industrial drives and controller platforms, supporting interoperability with Sanyo Denki servo amplifiers. Its combination of compact size, precise feedback, and robust overload protection makes the R11F432565 well-suited for robotics, CNC machine tools, automated assembly lines, and packaging machinery. Engineers will appreciate the motor’s straightforward mounting and electrical connections, as well as its ability to operate reliably in environments up to 90% humidity. For applications demanding high dynamic performance and reliable operation, the R11F432565 sets a benchmark in the ABS Super Servo Motors lineup.
