R911170365
The R911170365 (CFL01.1-E2), manufactured by Bosch Rexroth Indramat, is a highly functional module known for its swift signaling. Offering both inbound and outbound signals, this unit comes with eight pre-configured inputs and an equivalent number of freely configurable outputs. An additional eight channels can be assigned as either inputs or outputs. Typical signal delays for this model are 45 μs for inputs and 70 μs for outputs.
This appliance, designed for enhancing any CML control, is equipped with IP20 touch protection, safeguarding against fundamental dust and basic touch. With resilience against a wide range of atmospheric conditions (5-55°C) and relative humidity (5%-95%), the R911170365 (CFL01.1-E2) employs single wire technology for its inputs and outputs. It has a sensor supply of 24v DC with variable input voltage between <5 low and >11 high levels. This unit also utilizes a 24 V DC output voltage and is rated for an output current of 500mA and a lamp load of 5W. With a power consumption of 0.3W and SG1 (6.2W) protective outputs, the unit conforms to UL 508 certification for devices rated under 1500 volts, and is created for usage in sync with NFPA 70 National Electrical Code.
