R911170850
The R911170850 (VEP40.3CEN-256NN-MAD-128-NN-FW) is a high-performance HMI (Human-Machine Interface) panel from Bosch Rexroth’s IndraControl VEP40 series. With a 600 MHz Celeron M processor and Windows CE 4.2 operating system, it sports a 12.1-inch dedicated pc-based TFT display. The touchscreen panel hosts 256 MB of application memory, 128 MB flash size, and two compact flash slots, with one memory slot. Equipped with a Super VGA display capable of 800 x 600 resolution, it weighs approximately 3.8 kgs. Acceptable humidity for operation ranges from 5 to 85 percent, with a maximum input current of 1.5 Amps and inrush current of 7 Amps.
Designed for user ease, the R911170850 (VEP40.3CEN-256NN-MAD-128-NN-FW) features a touch screen interface with an integrated, virtual keyboard. Communication interfaces include a standard RS232 and two USB 2.0 ports. The DC 24-volt power supply does not include a brief UPS for data backup on the compact flash. This HMI complies with IP 20 and IP 65 protection classes, and it has a power input rating of 53 W. The operating voltage ranges between DC 19 V and DC 30 V and the operative temperature limits range from 5 to 45 degrees Celsius. Proving more efficient than traditional PC-type operator panels, the R911170850 (VEP40.3CEN-256NN-MAD-128-NN-FW) is a robust, cost-effective HMI solution.
