R911171081
The R911171081 (VAK40.1E-EN-U-MPNN), a product of Bosch Rexroth Indramat, is an industrial-grade keyboard that features a full layout including a mouse and numeric keypad. As a part of the IndraControl VAK 40 series, the keyboard is designed to function optimally in environments with an altitude of up to 1500 meters, a temperature of between 5 and 45 degrees Celsius, and relative humidity from 5% to 85%. The keyboard's operation also remains stable between 86 kPa and 106 kPa atmospheric pressure. Prevention from corrosive elements and vibrations is essential. When not in use, the unit can be safely stored up to 3000 meters altitude with a temperature range of -20 to 60 degrees Celsius.
Weighing roughly 2.6 kilograms, the R911171081 (VAK40.1E-EN-U-MPNN) keyboard measures 200mm in depth, 407mm in width, and 88mm in height. This product is recognized for its IP 65 protection rating and endures operating vibrations and shocks up to 0.25 g and 5 g respectively. It has a power consumption of 0.15 Watts, operates on an input voltage of 5 Volts DC, and features a current consumption of 30 milliamps. It is equipped with 86 keys in English and includes an integrated USB port. Scheduled maintenance and repairs should be performed by trained technicians and power should be disconnected prior to any installation.
