R911247199
The R911247199 (DDS02.1-W100-DS01-00) is a product of Bosch Rexroth Indramat, known for their exceptional range of automated devices including drive controllers, frequency converters, inverter modules, and motors. This specific model, the R911247199 (DDS02.1-W100-DS01-00), uses a consistent current of 40 A and is designed to be installed in a control cabinet with suitable protection and venting.
This model is equipped with a SERCOS interface communication card in the U1 slot and a firmware module in the U5 slot. It is affixed to the cabinet's rear wall using a mounting panel, allowing the heatsink and casing to extend out. Post-installation, a sealing ring at the mounting flange ensures the cabinet gap is closed off. The DDS02.1 drive controller can be custom configured via modules in the U1 – U5 slots, with the primary features including resolver feedback and a SERCOS communication module. While not waterproof due to an IP20 rating, it offers limited protection from liquids. This model is operational between 0 to +45 degrees Celsius and comes with a status LED to show errors or issues. It is most frequently used with machine tools, printing machines, and textile machine processes. Additional plug-in modules can be placed in the U2 to U4 slots. Weighing 7.5kg, the R911247199 (DDS02.1-W100-DS01-00) model has a peak current capacity of 100 amps and is widely recognized for its durability and quality in industrial automation.
