R911261313
The R911261313 (MKD041B-144-GP1-KN), a product by Bosch Rexroth Indramat, is a premium quality synchronous motor that's instrumental in the automation industry. Known for innovative designs and robust performance, this synchronous motor integrates top-notch features such as shielded power cables, efficient drive controllers, and hydraulic solutions, all contributing to its longevity and performance efficiency. It incorporates methods such as natural and surface cooling to prevent overheating, ensuring optimal functioning.
The motor's comprehensive mechanical data ensures correct storage, mounting, and transportation. Remarkably, it offers a rotor inertia of 1.7 x 10-4 kgm² and a maximum torque of 11.3 Nm, regardless of your preferred cooling method. The minimum strand cross-section is 1mm2, with an approximate thermal time constant of 30 minutes, and a speed rating of up to 7500 min-1. The weight is approximately 4.4kg, and optimal performance can be achieved at a mounting height up to 1000 meters NN. Suitable operational temperatures are 0°C to 40°C, while for storage or transport, the motor withstands -20 to +80 degrees Celsius. Rated data includes a torque range of 1.4Nm to 1.5Nm, a frequency spectrum of 150Hz to 225Hz, voltage range of 115 to 170V, current range of 2.8A to 3.0A, a rated speed of 3000 Nm - 4500 Nm, and power range from 0.52 KW to 0.88KW.
