R911263227
The R911263227 (DKS01.1-W050A-DG01-00) is a superior quality, digital servo drive designed and produced by Bosch Rexroth Indramat. Used in synchronization with MDD digital AC servo motors, this high-performance drive is designed for dynamic, high density power applications thanks to its compact and versatile design. This first-series servo drive features an effective, warm type cooling mode that efficiently dissipates cabinet heat. Its connectivity is facilitated by a single-phase power source, ensuring straightforward installation and operation. Highly precise monitoring and control of rotor position is made possible through the implementation of high-resolution measurements.
Noted for its standard noise emission during motor operation, the R911263227 (DKS01.1-W050A-DG01-00) possesses an integrated dynamic brake system, equipped to decelerate the motor as a safety measure. Key features of this module include ready-to-connect power connectors, a protective power shutoff system, programmable error reaction, and motor holding brake. This 50-amp rated current drive’s compatibility with other components can be confirmed with the configuration label, which holds crucial details like configured servo drive, software module, and type of plug-in cards. Installed in a control cabinet bearing a IP 10 rating, this unit is not protected against water entry or internal penetration. Depending on the user's unique needs, it offers great flexibility through configurability. Its multiple applications range from electronic gearbox use to packaging machines.
