R911264221
The R911264221 (TDA 1.3-100-3-D0I) Main Spindle Controller, brought to you by Bosch Rexroth Indramat, is specially designed for high performance. Equipped with various speed command interfaces like Digital, Analogue, and SERCOS, the device also includes additional interfaces for a Serial interface, Incremental encoder output, and input for digital position command. It is essential to operate this device in areas with ample humidity like workshops, ensuring that moisture does not condense on the unit.
Focusing on its technical specifics, the ambient temperature for the Main Spindle Controller at nominal ratings lies between +5° C to +45° C, and its storage and transportation temperature range is -30° C to +85° C. It's suitable for installation up to 1000 meters above sea level. With a +24V load voltage, its power consumption is 1.4 A, whereas at ±15V test voltage, it uses 160 mA. The maximum continuous effective current and current rating of R911264221 (TDA 1.3-100-3-D0I), with air inside the control cabinet, are 70 A and 100 A respectively. The unit weighs 10.5 Kg while the utmost permissible ambient temperature at reduced ratings is +55° C.
30 Day Warranty
Technical Specifications
