R911266335
Manufactured by Bosch Rexroth Indramat, a key innovator in motion control technology, the R911266335 (MDD071B-N-040-N2S-095PA0) is a part of the MDD series of advanced AC servo motors. The MDD071B model has been designed for high torque density and is ideal for harsh industrial environments including dust and pollution. With an IP65 protection rating, it offers a perfectly sealed housing safe for outdoor use. It features surface cooling optimized housing and can operate at a speed of 4,000 revolutions per minute. The motor can be mounted in any orientation, offers high synchronous operation and sinusoidal current application.
The R911266335 (MDD071B-N-040-N2S-095PA0) displays a high torque-inertia ratio, thus offering superior dynamics. It has been engineered for optimal peak torque over a wide speed range. Its total mass is 8.8 kg, and the thermal time constant is 45 minutes. The device functions optimally in temperatures between 0-40 degrees Celsius. For safe storage, an ambient temperature range between -20 to +80 degrees Celsius is recommended. Its finely balanced design, with a centering diameter of 95mm, makes this model a robust and reliable choice for various industrial applications.
