R911266504
The R911266504 (DKS01.1-W050A-DL04-01-FW) is a servo drive created by Bosch Rexroth Indramat, specifically designed to manage the MDD AC Servo Motor. It connects to the motor via separate power and feedback cables and is compatible with either a 3 phase or 1 phase 230 Volts AC voltage supply. Other signal cables are secured with screws and the unit features an alphanumeric display for troubleshooting purposes. Modules can be effortlessly integrated through slots U1 to U5, allowing for customization dependent on application requirements.
This unit incorporates a safety system that automatically cuts power in an emergency. Moreover, the inrush current is auto-regulated, negating the need for consideration during fuse or circuit breaker installation. Other features include an internal system that monitors the motor's holding brake, a dynamic braking system that safely decelerates and stops the drive during electronic faults, and a programmable routine for system faults. Notably, this drive has a peak current rating of 50A, emits standard noise at the motor, and operates optimally below an ambient temperature of 45 degrees C. Each unit is packaged in military-grade foam for worldwide delivery, ensuring a damage-free product upon arrival.
