R911266571
The R911266571 (DDS02.1-W050-DL08-01-FW) drive controller, produced by Bosch Rexroth Indramat, comes with default empty slots in the basic unit, indicative of the line code of ‘1’. The product is a single axis positioning module capable of programming up to 3,000 program blocks. After removing the faceplate, this unit can be installed and refitted with ease. It features a power section consisting of a DC bus voltage fluctuating around 300V, adjusting as per an overload factor during initialization.
Approximately weighing 7.5kg, the controller's current consumption constitutes the combined values from plug-in modules, the elementary unit, and the motor feedback. The product can function effortlessly up to a limitation of 55°C, and shouldn’t be placed near remote control and high-frequency equipment. Notably, it is developed to be manipulated and mounted with appropriate machinery and tools while avoiding any potential mishaps.
The final configuration of the controller consists of both firmware and hardware, whose functions are determined by the specific device. It includes a status display for error and warning messages. The controller is linked to the neighboring unit through DC bus rails and has an in-built software slot. The X4 connector establishes the motor feedback connection, and the power cable between the device and AC motor shouldn't exceed a length of 75m.
