R911270586
The R911270586 (DDS03.1-W050-DA01-01-FW) is a drive controller produced by Bosch Rexroth Indramat. As an AC digital servo drive, it should be utilized firmly within stipulated guidelines to avoid bodily harm or damage to equipment. It is characterized by a version code of 1 and a series code of 2. Any work on the device should only commence after it has been switched off for at least five minutes. For safety against unintentional startup, its power connection can be isolated via an emergency stop circuit. Communication is accomplished through an analog interface, which also incorporates digital servo feedback. Commissioning is facilitated by an IKS3091 service cable. The analog interface supports both incremental and absolute encoder emulators and comes with signal outputs and control inputs. Firmware must be procured separately and installed in the U5 slot.
Particular attention must be paid during the setup process. The faceplate, removed during installation, should be properly reattached. The device is designed to function optimally at altitudes up to 1,000m above sea level and it's safeguarded against the intrusion of solid objects exceeding 50mm in diameter. The necessary control electronics are supplied via the X1 connector, and a bus cable, identifying with a black core at the bottom, should be used for the connection between the drive controller and the supply unit. The device is ready for operation when the Ready-to-Operate contact is sealed.
