R911271048
The R911271048 (MKE096B-047-KP0-KN) is a permanent magnet motor designed and manufactured by Bosch Rexroth Indramat, a well-known company in the field of motion and logic control operations. To cater to a diverse range of applications, Rexroth Indramat has developed an array of motors such as digital motors, direct drive motors, asynchronous motors, and synchronous motors. The R911271048 (MKE096B-047-KP0-KN) belongs to the company's MKE series, specifically engineered for use in potentially explosive areas. The series satisfies global safety standards including ATEX, CSA, and UL, making them universally suitable. Although primarily consisting of four standard models, certain units within the MKE range can be customized to meet clientele's distinctive needs.
Characterized by notable performance, the R911271048 (MKE096B-047-KP0-KN) is a synchronous motor from the second generation of the MKE series. It delivers a maximum speed of 4,500 RPMs and operates with a current capacity of 13.2 Amperes. With a maximum torque of over 43 Nm, and a low rotor inertia of 0.00430 kgm2, the motor can quickly alternate between velocity levels. The motor's robust winding offers 8.4 ohms resistance and can withstand an ambient temperature of up to 155 degrees Celsius. This motor's structure, designed for hazardous environments, incorporates four pole pairs and features IP65-rated protection, safeguarding it from dust and water infiltration. Furthermore, this 18kg servo motor, belonging to the 'B' category of motor length, comes with a 96mm frame and a shaft with keyway in compliance with DIN 6885, sheet 1.
