R911273183
The R911273183 (DDS02.1-W050-RL02-01-FW) is a DDS series drive controller, fabricated by Bosch Rexroth Indramat, from the DIAX02 product group. This modular drive swiftly responds when synchronized with Bosch's LAR, MKD, and MDD AC motors series. Before using this drive controller, make certain the application complies with national EMC directives. The device remains electrically active when switched on, thus, its components should not be touched, and the earth wire should be connected before testing to prevent high voltages. For safety purposes, its operation should be halted before entering the danger zone. This controller effectively utilizes heat technology for cooling and comes with two configuration rating plates for easy software and hardware identification.
The R911273183 (DDS02.1-W050-RL02-01-FW) uses resolver feedback for operations. Due to heat dissipation inside the cabinet, air conditioning may be necessary. Weighing approximately 7.5kg, the device adheres to the IP 10 protection category as per DIN 40 050 standards. It requires the use of D subminiature plugin connectors or plugin clamps for signal lines, and shielded leads for analog signals. All components are VDE 0160 tested for high-voltage operations. In case of multiple controllers, they can be connected via a DC bus rail. It also includes a single-axis positioning control communications module, supporting up to 3,000 program blocks. The controller's operational readiness is indicated by a Bb contact with a switching capacity of 1A and 24VDC.
