R911273293
The R911273293 (DDS02.1-W150-DL40-01-FW) is a high-quality drive controlling component, courtesy of Bosch Rexroth Indramat. It forms a key part of the modular DDS drive system, a compact setup that requires just one supply unit, optimized for user versatility. When paired with MDD and MKD synchronous motors, as well as LAR and LAF linear induction motors, it creates a rapid-response drive. Its usage spans various platforms like machine tools, textile manufacturing, robotics, and packaging machinery.
This specific model boasts a current rating of 150A and operates optimally at a DC bus voltage of 300V, allowing a variance of ±15%. Its cooling efficiency is due to the heat technology mechanism that advocates for the airflow within the control cabinet. The main benefit of this cooling method is its minimal mounting and installation requirements, although it does necessitate a spacious control cabinet and air conditioning. This drive controller can be transformed into a stand-alone single-axis positioning unit with its unique plugin module. Its program can monitor 3,000 program blocks, with each one representing a unique motion sequence or the statuses of inputs and outputs. The firmware, responsible for the functional features, can be individually ordered and re-ordered as per need. Furthermore, it maintains an Ingress Protection rating at IP 20 according to EN 60529.
