R911277119
The R911277119 (MHD112D-024-NP0-AN) is a cutting-edge AC servo motor by Bosch Rexroth Indramat, a part of the MHD series of synchronous motors. MHD motors are permanent magnets that showcase commutation and are combined with Bosch Rexroth's drive controllers to create versatile automation systems. Suitable for application in numerous industries, the broad torque range of the MHD series enables their use in handling and automation systems, machine tools, as well as food packaging, printing and paper industries.
The R911277119 (MHD112D-024-NP0-AN) comes with a frame size of 112 and length D and offers self-cooling via its special housing design. Rated IP 65, the motor is fully safeguarded against dust and low pressure water jets, hence it is well-suited for adverse environments. Additionally, the motor is built according to class F insulation as per DIN VDE 0530 standards. It's painted black to offer further protection against diluted chemicals. An optical digital servo feedback encoder ensures system accuracy of ±0.5 angular minutes, and the motor features flange socket power connection too. Despite not having a holding brake, it is compatible with all blower units suitable for MHD 112 motors.
