R911278174
The R911278174 (MKD090B-035-KP1-KN) is a high-performance synchronous motor from Bosch Rexroth Indramat, part of the esteemed Rexroth Bosch Group. Renowned for designing cutting-edge engineering solutions, their latest offering caters specifically to drive tool applications. This innovative motor combines superior materials to ensure uninterrupted power delivery, even at high speeds. For optimizing performance, it employs both natural and surface cooling methods, the former ranging from 100K to 60K and the latter at 60K/100K.
Elaborating on its technical aspects, the electrical parameters of this motor endorse efficiency and cost-effectiveness. Peak current at standstill is 49.5 A for both cooling types, while continuous torque levels at standstill stand at 18.0 Nm for surface cooling and between 12.0-13.5 Nm for natural cooling. The motor's mechanical parameters add to its safety features and maintenance ease. It has a rotor inertia of 43.0 x 10-4 Kg/m2, and the motor mass is approximately 14.0 Kg. The motor can reach a maximum speed of 5000 min-1 under either cooling method and is designed within the protection category of IP65 and insulates to Class F under DIN VDE 0530 part 1.
