R911278547
Product R911278547 (DDS02.2-W050-BE24-02-FW), from Bosch Rexroth Indramat, is a DDS series drive controller. When this controller interfaces with AC servo and primary drives, it generates a compact drive package that operates from a single power supply. The DDS drive system, of which this controller is a part, is both modular and versatile. These controllers, when used with AC servo motors, function as swift-response drives, ideal for use in textile machines, robotics, and handling systems.
The R911278547 (DDS02.2-W050-BE24-02-FW) is a second version drive controller of the DDS series, featuring unique heat technology cooling. This cooling process disperses heat within the controller's control cabinet, requiring a spacious, air-conditioned control cabinet. The same cabinet houses the controller's power supply. This proprietary design ensures that all Indramat power units maintain a regulated DC 24V voltage. The controller comes with a SERCOS plug-in module, offering inputs for evaluating reference and range limit switches, and sensor inputs. This system operates at a rated current of 50A and maintains a DC bus voltage of 300V, tolerant of ±15% variation. It is compatible with motors having digital servo feedback and resolver feedback, and functions optimally at temperatures of up to 45oC and installation heights of 1000m or under.
