R911279114
The R911279114 (MDD112D-N-030-N2L-130PL2), created by Bosch Rexroth Indramat, is a synchronous motor ideal for high-precision industrial applications requiring exceptional synchronization. Manufactured in compliance with international quality standards, this highly adaptable motor is compatible with a broad spectrum of industrial machinery such as grinding and metal forming machines, and handling systems. Its brushless design ensures peak operational efficiency with minimal environmental disruption. With an IP65-rated housing containing a high percentage of metal, this motor guarantees enduring protection for its internal components.
Equipped with a grease-lubricated ball bearing system, the R911279114 (MDD112D-N-030-N2L-130PL2) synchronous motor effectively minimizes the heat triggered by friction during operation. It boasts a rated rotational speed of approximately 3,000 RPM, ramping up to a maximum of 6,000 RPM, producing an output torque of around 130.2 Nm per Ampere when operating at peak input current of 222.2 A. It also features an electrically releasing holding brake with a holding torque of 40 Nm, utilized for retaining the radial load when the motor is not active. The internal temperature of the R911279114 (MDD112D-N-030-N2L-130PL2) motor is managed through natural convection. However, an external air blower can augment the cooling process for best operational efficiency.
