R911279418
Original price
$28,383.60
-
Original price
$28,383.60
Original price
$28,383.60
$28,383.60
-
$28,383.60
Current price
$28,383.60
The Bosch Rexroth Indramat R911279418 (MHD093B-035-NG1-AN) is a state-of-the-art industrial synchronous motor, skillfully constructed to transform electrical energy into kinetic energy for efficient industrial equipment functioning. This motor is brushless and encased in a black coat (IP65 protection level), offering a safeguard against damage from liquids like dilute acids, seawater, hydraulic oils and more. The R911279418 (MHD093B-035-NG1-AN) is capable of continuous start-stop functions due to its electrical commutation, and provides a remarkable range of peak torque.
Performance of the R911279418 (MHD093B-035-NG1-AN) depends on surface temperature: at 60K, it offers a rated torque output of 12.0Nm using an input current of 10.2A. However, at 100K of surface temperature, it increases torque to approximately 14.0Nm and utilizes 11.9A. The motor reaches a peak rotational speed of 4500rpm, consuming a maximum of 45.9A through its power cable. A standout feature is its electrically released holding brake which keeps the linked equipment steady while the motor is inactive. Operating at an electrical current of 0.71A, it delivers a holding torque of up to 22Nm.
30 Day Warranty
Technical Specifications
