The Bosch Rexroth R911282633 (MHD112D-027-NG0-BN), part of the MHD series, is an industrial servo motor with a maximum rotating speed of 3000 RPM and a rated speed of 2000 RPM. Performance statistics vary based on cooling method and operating conditions. With natural convection at 60K over temperature, desired statistics such as torque, current, power output, and voltage are 27.3 Nm, 12.7 Amps, 6.9 kilowatts, and 319 Volts respectively. These outputs significantly increase under different operating conditions with the maximum achievable outputs presenting at a rated speed of 2000 RPM, a torque of 59.2 Nm, current of 27.6 Amps, power output of 15.2 kilowatts and voltage of 344 Volts, all under surface cooling conditions.
Across all operating conditions, the motor frequency remains constant at 133 Hertz. The thermal time constant varies between 40 to 90 minutes, depending on the cooling method. This robust motor, weighing in at 56 kilograms, comes with an IP65 protection rated housing. It features digital servo feedback, a plain shaft with a seal ring, and no holding brake, although optional holding brakes can be ordered separately. The power connector is placed on Side B. Lastly, the R911282633 (MHD112D-027-NG0-BN) is flange-mounted, with a flange size measuring 192 millimeters.
