R911282661
Bosch Rexroth Indramat is renowned for its development of industrial motion control systems and synchronous motors, one of which is the highly durable R911282661 (MHD071B-035-NP1-UN) servo motor. The motor is engineered for exceptional speed and precision control, making it ideal for use in a diverse array of industrial machinery including paper manufacturers and printers, woodworking equipment, automated systems, machine tools, and food processors. It is known for its robust operation amid harsh environmental conditions, thanks to an IP 65-standard enclosure that shields the motor's internal hardware against dust, debris, oils, and emulsions. The motor's peak performance is attainable when paired with drive controllers from the same manufacturer, due to its sophisticated internal positioning system enabling precise positioning despite fluctuating speeds.
The R911282661 (MHD071B-035-NP1-UN) model operates characteristically at 4500 rpm, providing a continuous torque of 8 Nm during its standstill phase at a motor overtemperature of 60 K, and at 100 K, the continuous torque measures 13.2 Nm. This model, categorized under insulation class F, is specifically recommended for use within the 0 °C to 40 °C temperature range for optimal performance. Possessing a peak current of 50.5 A and a torque constant of 0.77 Nm/A, this model can achieve a maximum speed of 6000 rpm. It also boasts a low rotor inertia feature enabling quick start-stop applications.
