R911283384
The Bosch R911283384 (MHD112D-027-PG3-BN) is part of the Indramat Rexroth MHD series of synchronous motors. This state-of-the-art product features digital servo feedback with an integrated multiturn absolute encoder for precise positioning and controlled motion. The unit is equipped with a 70 Nm holding brake which utilizes the electrical release principle to securely clamp the servo axis when the motor is not powered. This motor contains an electrical connector on side B and possesses a 112D frame size and frame length. It employs a 027 winding code.
This versatile machine has a plain, sealed shaft and a robust housing rated for IP65, affording protection from dust and low-pressure water jets from any direction. It utilizes natural convection or surface cooling and is certified under insulation class F as per DIN VDE 0530. The R911283384 (MHD112D-027-PG3-BN) operates at an optimal temperature range between 0 to 40 degrees Celsius and a storage temperature range of -20 to 80 degrees Celsius. The motor runs at a rated speed of 2000 RPM and generates rated torque between 27.3 Nm at 60K and 59.2 Nm at 60K/100. Weighing 56 kilograms, it is rated up to a maximum installation altitude of 1000 meters. This motor excels in various applications, including machine tools, food, and packaging machines, and automation systems.
