R911284231
The R911284231 (CCD01.1-KE19-01-FW) is a top-tier box terminal, produced by Bosch Rexroth Indramat. Primarily compatible with the latest control section, it offers a dual interface with two connectors. The product utilizes a Sercos III interface for connection with the control section, meeting the stringent IEE 802.3 standards. The boxing terminal employs RJ-45 connectors, each with eight pins, though pins 4, 5, 7, and 8 serve no function. Connections are established through CAT 5 terminals, all enclosed within a shield-connected housing.
Possessing two differential inputs (RD+ and RD-) and two differential outputs (TD+ and TD-), it receives and sends 10/100 Base-T signals. The firm's available firmware assures optimal running of the box terminal. Its interface satisfies the IEEE 802.3i and IEEE 802.3u standards for 10 Base-T and 100 Base-T signals respectively. Status information is provided through a series of LEDs- H1 depicting power status, H10 and H12 translated in data transmission status and H11 as well as H13 indicating network availability. The box terminal boasts a differential input and output on each connector. These receive and despatch 10/100 Base-T signals.
