R911284637
Product R911284637 (MHD112B-048-PP0-AN), a sophisticated and intricate piece of machinery, is a testament to Bosch Rexroth Indramat's unparalleled innovation and expertise in the realm of digital motor technology. The company's reputation rests on its exceptional mechanical engineering capabilities and its ability to introduce ground-breaking designs, such as its drive and control systems. One key technological advancement that sets Bosch Rexroth apart is the IndraDrive, a modular designed system that promotes efficiency by enabling seamless integration of parts to operating systems. Besides being adaptable for diverse applications including robotics, printing machines, and textiles, this system significantly enhances safety, making Bosch Rexroth a leading name in the industry.
The R911284637 (MHD112B-048-PP0-AN) servo motor, a part of the MHD Synchronous Motor series, exhibits the brand's commitment to reliability and proficiency. The motor is characterized by a 192mm flange size, 130mm centering diameter, and 28 Nm motor frame length. The motor, equipped with a winding code of 48 and devoid of holding brakes, is designed to endure rigorous tasks under diverse conditions. It also features a liquid-cooled housing and a connector output directed towards side A. The motor's output shaft, fitted with a sealing ring, adheres to DIN 6885-1 standards. In addition, the motor has an integrated multi-turn digital encoder for efficient feedback. With a rated speed of 2800 min-1, a moment of inertia at 192.0x10-4, and a theoretical maximum torque of 102.0 NM, the R911284637 (MHD112B-048-PP0-AN) motor promises superior speed and control.
