R911285854
The R911285854 (BTC06.2A-F-EH3-FW) is a compact and portable control panel from the BTC06 series, created by Bosch Rexroth Indramat. The unit is suitable for controlling single and multiple axis installations across various applications such as machine tools, packing machines and assembly systems. It should operate within the parameters stated in the product documentation. Any misuse - such as use in unsuitable environments, failure to adhere to safety measures or use of unapproved accessories - may result in injury, electric shock or death. The unit operates with a 20-30 Volt DC input and utilises 400 milliamps max current. The display features a 240 x 128-pixel resolution LCD with a display area of 108 x 58 mm.
The R911285854 (BTC06.2A-F-EH3-FW)’s enclosure is formed of polycarbonate and possesses IP 65 protection. The unit has an RS-232 interface that comes with a protective cap. With an approximate weight of 1.3 kg, this unit measures 315 mm in length, 180 mm in width and 57 mm in depth. The operating temperature falls between 32 to 131 degrees Fahrenheit, while the storage temperature is from -4 to 158 degrees. The control panel functionality includes a handwheel, emergency stop switch, override potentiometer and a three-state dual circuit activate button. Firmware and additional components must be ordered separately. The emergency switch operates at a rated voltage of 24 Volts DC / 42 Volts AC and a rated current of 2 Amps DC / 3 Amps AC.
