R911292602
The R911292602 (MKE098B-047-KP1-BUNN) synchronous motor is a high-quality product fabricated by Bosch Rexroth Indramat, adhering to the guidelines of EN 60079/0/1/31. This motor possesses a length code of B and is optimized for industrial-use only, with both core functions as a rotary main motor and a servo drive motor. The R911292602 (MKE098B-047-KP1-BUNN) integrates permanent magnets in the rotor to facilitate electronic commutation and features a flange design to simplify the connection process with machinery. An important element to remember about this device is that it requires programming of the connected drive control prior to the start-up to ensure precise execution of application-specific functions.
Emphasizing the safety measures, the motor, rated with 9.8A continuous current at standstill at 60K, is not intended for underwater operation. Also, it is recommended that the associated drive is approached half an hour after the power supply is cut, allowing complete discharge of capacitors. The setup includes a keyway shaft that aligns with DIN 6885-1 parameters and one shaft-sealing ring. With the encoder's data memory storing critical parameters, the product assures a safe shutdown via integrated PTC resistors. The motor can withstand a maximum surface temperature of up to 135°C and is designed to be grounded through a secondary connection. To ensure safe delivery, the unit is shipped in military-grade custom packaging to prevent transit damage.
30 Day Warranty
Technical Specifications
