R911296636

Original price $11,489.10 - Original price $11,489.10
Original price
$11,489.10
$11,489.10 - $11,489.10
Current price $11,489.10
In Stock, Ships 3 - 5 Days
Request a quote
The R911296636 (MHD112D-027-PG3-LN) from Bosch Rexroth Indramat is a compact yet high-quality product with a weight of 56 kilograms. Renowned for their technological innovations, Bosch creates drive controllers, inverters, frequency converters, and top-notch synchronous motors just like this model. Despite its size, the R911296636 (MHD112D-027-PG3-LN) offers remarkable performance, even in tight installations within a 1000 meter height above sea level. This synchronous motor, designed for surface cooling, operates optimally between 0 to 40 degrees Celsius and offers a rated torque of 59.2 Nm at a rotational speed of 2000 RPM while consuming 27.5 A. The MHD112D version houses an output shaft and power connection to the left, producing a maximum torque of 187 Nm with an elevated speed limit of 3000 RPM. This specific model features a 3.8-kilogram holding brake with a holding torque of 70 Nm. Furthermore, the R911296636 (MHD112D-027-PG3-LN) is corrosion-resistant with IP68-rated protection against dust and moisture and a resilient black RAL 9005 painted housing. This model, equipped with an absolute multiturn encoder, offers a continuous torque of 48 Nm during natural cooling while using 31.6 A during a standstill.
30 Day Warranty
Technical Specifications
  • Continuous Torque (natural cooling): 48 Nm
  • Enclosure Rating: IP68
  • Manufacturer: Bosch Rexroth Indramat
  • Operating Temperature: 0 to 40 degrees
  • Power Connection: Left side
