R911305136
The R911305136 (MKD093C-058-KG1-AF) is a Bosch Rexroth Indramat-manufactured servo motor, equipped with a 22 Nm integrated holding brake. The motor boasts operating specifications including a maximum speed of 6000 RPM, and rated torques of 23 Nm for convection cooling mode and 43.7 Nm for liquid cooling mode. It also features 28.3 Amps and 53.8 Amps rated current for convection and liquid cooling modes respectively, alongside a voltage constant of 82.7 Volts / 1000 RPM and torque constant of 0.91 Nm/A - the latter two specifications valid at a 20-degree Celsius ambient temperature. The R911305136 (MKD093C-058-KG1-AF) supports resolver feedback and an integrated multiturn absolute encoder, with additional features like a plain shaft with shaft sealing ring, and power / encoder connector on side A. The motor holds an IP 65 rated enclosure that is prime black coated, and features an F insulation rating as per DIN VDE 0530.
Adherence to recommended operational conditions for the R911305136 (MKD093C-058-KG1-AF) motor, which include a maximum installation elevation of 1000 meters and temperature between 0 to 45 degrees Celsius, is advised. The motor can run up to 55 degrees Celsius and elevations beyond 1000 meters, but with output reduced to 80% and approximately 70% of rated values respectively. Adjustments using the utilization factor should be made if exceeding the recommended values, ensuring the altered torque data still meet application requirements. A careful handling of the motor during transport or installation, in line with the manufacturer's guidelines, is crucial to prevent equipment damage.
