R911305292
The product, R911305292 (VSP16.1DBE-512NN-C1C-AD-NN-FW), is a computer-based industrial operator terminal developed by Bosch Rexroth Indramat. Belonging to the VSP 16, Series 1, the terminal is equipped with a 12-inch TFT touchscreen display, which might require a replacement once its brightness reduces to 50% after approximately 50,000 operational hours. Adorned with a light grey IP 65 rated front panel that includes a USB interface, the terminal also houses a Type E PC box with 6 PCI slots designed for plug-in cards. The processor is an Intel Celeron with a minimum clock speed of 2 Gigahertz and features an in-built graphics controller with up to 8 Megabytes of memory. Storage is taken care of by a 20-Gigabyte hard drive (which may require replacement during the terminal's lifespan), and 512 Megabytes of RAM.
Additional features of the R911305292 (VSP16.1DBE-512NN-C1C-AD-NN-FW) terminal include a DVD-ROM optical drive and factory-installed operating system, along with physical interfaces such as VGA, 10/100BASE-T Ethernet, RS-232 serial interface, parallel interface, two Type A USB ports, and PS/2 inputs for a keyboard and mouse. Powering this AC-powered terminal is a peak power draw of 330 Watts with an input voltage range of 115 to 230 Volts AC and a current input between 5.0 Amps to 2.5 Amps. Of note, VSP series terminals can also operate with 24 Volts DC power supplies. It is advised that the terminal is ideally stored and transported within temperatures ranging from -20 to 60 degrees Celsius.
30 Day Warranty
Technical Specifications
Get In Contact
Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products, all warranties are with Servo Supplier and not the manufacturer.
