R911306775
Original price
$707.03
-
Original price
$777.73
Original price
$777.73
$707.03
-
$777.73
Current price
$777.73
The Bosch Rexroth Indramat's R911306775 (HNL01.1E-1000-N0012-A-500-NNNN) is a Mains Choke from the reputable HNL series. This unit, weighing 2.7 kilograms, is designed for connection to non-regenerative components and is equipped with a rectifier supply system. It's categorized as a device type A and pairs with the HCS01.1E-W0028 compact converter. This unit is also suitable for converters used in residential areas. It operates at a nominal current of 12 Amperes (at 40°C), with a rated nominal inductance of 3 x 1000 µH and a power dissipation of 40 Watts.
Mains chokes such as this one function well when the mains short-circuit current is at most 100 kA and the supply mains unbalance is about 1.8 % or more. This model's voltage operates in the range of 380 V -15 % to 500 V +10 % and runs at a mains frequency of 50 to 60 Hz (±5 %). Its compact dimensions include a width of 120mm, a height of 164mm, and a depth of 61mm. This unit is designed to operate in temperatures ranging from -10°C to 50°C and can be stored in temperatures between -40 and 70°C. The R911306775 (HNL01.1E-1000-N0012-A-500-NNNN) is designed for optimal operation at 0 - 1km ASL, but can function up to 3km ASL when the mains choke data is reduced.
