Produced by market leader Bosch Rexroth Indramat, the R911307899 (MHD112D-027-PG0-LN) model is recognized for its energy efficiency and durability. The product portfolio includes advanced synchronous motors, servo motors, spindle motors, brake choppers, and drive controllers. The R911307899 (MHD112D-027-PG0-LN) model, in particular, features a voltage constant of 154.5 V/1000min-1 and a torque constant of 1.7 Nm/A at 20 degrees Celsius.
This model features a power connection on the left side of the motor housing, coupled with a plain output shaft. A sealing ring is positioned to keep lubricants intact. With natural cooling, it delivers a consistent torque of 48 Nm at 60 K, consuming a steady power of 31.6 A at the same temperature. Designed to accommodate both natural and surface cooling, the motor's framework is layered with black paint up to 40 micrometers thickness. The motor has a weight of 56 kgs without attachments, a winding resistance of 0.35 ohms, and a winding inductivity of 5.65 mH. It can achieve a maximum speed of 3000 revolutions per minute, generating a maximum torque of 187 Nm. The model R911307899 (MHD112D-027-PG0-LN) is especially reliable in challenging environments due to its high protection class of IP68, an insulation class of F, and a thermal time constant of either 40 or 90 depending on the chosen cooling method.
